Agastat TE CONNECTIVITY GPDN GPDNR 125 VDC Coil Voltage 10 A 4 Form C GP Series
Signal Relays 120 VAC Contact Voltage 6 mW Coil Power (DC), Socket, Plug-In, 125 VDC Coil Voltage, 10 A, 4 Form C (4PDT), Agastat GP Series
The AGASTAT GP series 10A Control Relay with non-latching, latching and timing versions. AGASTAT control relay is operated by a moving core electromagnet whose main gap is at the centre of the coil. The coil provides a low mean turn length and also assists heat dissipation. Since the maximum travel of the electromagnet does not provide optimum contacts movement, an ingenious amplifying device has been designed. When the centre of the W is moved vertically the lower extremities move closer to each other as can be seen in the illustration. The centre of the W mechanism is connected to the moving core of the electromagnet and the two lower points are connected to the moving contacts. Two of these mechanisms are placed side-by-side to actuate the four contacts sets of the relay. These arms act as return springs for their corresponding contacts. The plastic dust cover has two windows to facilitate cooling and also to allow direct mounting of the relay.
  • Occupies very small panel space
  • May be mounted singly, in continuous rows or in groups
  • Available with screw terminal moulded socket
  • 4 SPDT contacts
    • Agastat
      •
    • Agastat GP Series
  • TE Internal #: 1423155-6
  • TE Internal Description: GPDN=RLY,GEN,PURP,125VDC
  • Contact Voltage Rating (VAC): 120
  • Signal Relay Coil Power Rating (DC) (mW): 6
  • Signal Relay Mounting Type : Socket
  • Signal Relay Terminal Type : Plug-In
  • Signal Relay Coil Voltage Rating (VDC): 125
    Product Type Features

    • Relay Type : Control
    • Product Type : Relay
    • Relay Style : Power
    Electrical Characteristics

    • Contact Voltage Rating (VAC): 120
    • Signal Relay Coil Power Rating (DC) (mW): 6
    • Signal Relay Coil Voltage Rating (VDC): 125
    • Signal Relay Contact Switching Voltage (Max) (VAC): 120
    • Signal Relay Coil Magnetic System : Monostable, DC
    • Coil Type : Monostable
    • Input Voltage (VDC): 125
    • Actuating System : DC
    Contact Features

    • Signal Relay Terminal Type : Plug-In
    • Signal Relay Contact Current Rating (A): 10
    • Signal Relay Contact Arrangement : 4 Form C (4PDT)
    • Contact Number of Poles : 4
    • Contact Special Features : Magnetic Blowout
    Termination Features

    • Termination Type : 16 Flat Base Pins
    Mechanical Attachment

    • Signal Relay Mounting Type : Socket
    Dimensions

    • Width : 45 mm [ 1.722 in ]
    • Length : 45 mm [ 1.772 in ]
    • Dimensions (L x W x H) (Approximate) (mm): 45 x 45 x 109
    • Height : 118 mm [ 4.64 in ]
    Usage Conditions

    • Operating Temperature Range (°C): 0 – 60
    Operation/Application

    • Option : Magnetic Blowout Device
    Packaging Features

    • Packaging Method : Box & Carton
